UB400 6 Zone Walk Through Gate (Uniqscan China)

UB400 6 Zone Walk Through Gate

The UB400 model represents the next evolution in security technology. Engineered with cutting-edge
electromagnetic induction technology, it offers precise detection of magnetic metals, triggering immediate
alarms when threats such as firearms, knives, or other prohibited items are detected.

Technical Parameters

• Detection Zones: 6 zones
• Sensitivity: 2000 levels
• Calibration: Automatic
• Control Panel: Digital LED display
• Optics Control: Infrared sensor (1 pair)
• Infrared Beam Mode: Bidirectional
• Alarm Indicator: LED light and sound
• Traffic Indicator: Walk/Stop
• Tamper-proof Setting: Digital password
• Infrared Passing Speed: 30–40 people/min

🔹 Electrical Parameters

• Power Mode: AC-DC adapter
• Adapter Power:
  • Input: AC 100–240V ~ 50/60Hz
  • Output: DC 12.0V – 5.0A (60W)
• Working Voltage: DC 12V / 3A
• Working Frequency: 7KHz – 9KHz

🔹 Environment

• Operating Temperature: -20°C to 65°C
• Working Humidity: 0–95% (no condensation)
• Usage: Indoor / Outdoor
• Protection Level: CARB P2

🔹 Construction

• Door Panel: High Density Fiberboard
• Crossbeam Frame: Aluminum alloy
• Colour: Silver Grey, Black
• IP Level:
  • IP54 for Silver Grey MDF material models
  • IP65 for black PC material models

🔹 Warranty & Certification

• Warranty Time: One year
• Certifications: CE, ISO9001, FCC, ROHS
